CHEMICAL TANKER

2022 © KITANIHON SHIP BUILDING

40,000DWT TYPE

L_185m / B_29.20m / D_16.40m / d_11.35m
GT_24,400 / NT_11,000 / DWT 40,700 t
SERVICE SPEED 13.8 knots
CARGO TANK CAPACITY 44,400 m3
NUMBER OF CARGO TANKS 18Tks

37,000DWT TYPE

L_180.00m / B_28.20m / D_16.3m / d_11.35m
GT_23,000 / NT_9,800 / DWT_37,300 t
SERVICE SPEED14.0 knots
CARGO TANK CAPACITY 39,200 m3
NUMBER OF CARGO TANKS 28 tks

25,000DWT TYPE

L_160.00m / B_25.00m / D_14.80m / d_10.50m
GT_16,200 / NT_7,900 / DWT_25,200 t
SERVICE SPEED14.0 knots
CARGO TANK CAPACITY 30,200 m3
NUMBER OF CARGO TANKS 18 - 26 tks

19,990DWT TYPE

L_145.00m / B_24.20m / D_13.20m / d_9.75m
GT_12,200 / NT_3,300 / DWT_19,990 t
SERVICE SPEED 13.8 knots
CARGO TANK CAPACITY 22,400 m3
NUMBER OF CARGO TANKS 14 - 22 tks

12,500DWT TYPE

L_126.00m / B_20.50m / D_11.50m / d_8.70m
GT_8,300 / NT_4,200 / DWT_12,500 t
SERVICE SPEED 13.60 knots
CARGO TANK CAPACITY 12,600 m3 (POx Loading Capacity 9,100m3)
NUMBER OF CARGO TANKS 14 - 18 tks

6,800DWT TYPE

L_107.40m / B_ 16.80m / D_8.30m / d_6.80m
GT_4,200 / NT_2,100 / DWT_6,800 t
SERVICE SPEED: 13.0 knots
CARGO TANK CAPACITY 7,500 m3
NUMBER OF CARGO TANKS 12 - 13 tks
